THREAD

DIMENSIONS

PART NO.

E

F

A

B

S

L

6B-04

G1/4"X19

G1/4"X19

12

35

19

53

6B-04-06

G1/4"X19

G3/8"X19

12

35

22

55

6B-06

G3/8"X19

G3/8"X19

13.5

35

22

56.5

6B-06-08

G3/8"X19

G1/2"X14

13.5

39

27

62.5

6B-08-06

G1/2"X14

G3/8"X19

16

35

27

61

6B-08

G1/2"X14

G1/2"X14

16

39

27

65

6B-08-16

G1/2"X14

G1"X11

16

50

41

79

6B-10

G5/8"X14

G5/8"X14

17.5

40

30

67.5

6B-12-08

G3/4"X14

G1/2"X14

18.5

39

32

68.5

6B-12

G3/4"X14

G3/4"X14

18.5

42

32

71.5

6B-12-16

G3/4"X14

G1"X11

18.5

50

41

82

6B-16

G1"X11

G1"X11

20.5

50

41

84

6B-20

G1.1/4"X11

G1.1/4"X11

20.5

52

50

89.5

6B-24

G1.1/2"X11

G1.1/2"X11

23

55

55

93

6B-32

G2"X11

G2"X11

25.5

55

70

97.5
