THGEAD

DIMENSIONS

PAGT NO.

E

F

A

C

L

S1

S2

2BJ-02-04WD

G1/8"X28

7/16"X20

8

9

23.5

14

17

2BJ-04-05WD

G1/4"X19

1/2"X20

12

9.5

28.5

19

17

2BJ-04-06WD

G1/4"X19

9/16"X18

12

10.5

28.5

19

19

2BJ-04-08WD

G1/4"X19

3/4"X16

12

11

30.5

19

24

2BJ-04WD

G1/4"X19

7/16"X20

12

9

28

19

17

2BJ-06-08WD

G3/8"X19

3/4"X16

12

11

33

22

24

2BJ-06WD

G3/8"X19

9/16"X18

12

10.5

31

22

19

2BJ-08-06WD

G1/2"X14

9/16"X18

14

10.5

33.5

27

19

2BJ-08-10WD

G1/2"X14

7/8"X14

14

13

38

27

27

2BJ-08WD

G1/2"X14

3/4"X16

14

11

37.5

27

24

2BJ-12-16WD

G3/4"X14

1.5/16"X12

16

16

42.5

32

41

2BJ-12WD

G3/4"X14

1.1/16"X12

16

15

42.5

32

32

2BJ-16WD

G1'X11

1.5/16"X12

18

16

46.5

41

41

2BJ-20-16WD

G1.1/4"X11

1.5/16"X12

20

16

50.5

50

41

2BJ-20WD

G1.1/4"X11

1.5/8"X12

20

17

54.5

50

50

2BJ-24WD

G1.1/2"X11

1.7/8"X12

22

20

58.5

55

55
