THREAD

DIMENSIONS

PART NO.

E

F

A

B

S

L

1BM-02-10

G1/8"X28

M10X1

10

8

14

24

1BM-02-12

G1/8"X28

M12X1.5

10

12

17

28

1BM-04-10

G1/4"X19

M10X1

12

8

19

26

1BM-04-12

G1/4"X19

M12X1.5

12

12

19

30

1BM-04-14

G1/4"X19

M14X1.5

12

13

19

31

1BM-04-16

G1/4"X19

M16X1.5

12

14

22

34

1BM-04-18

G1/4"X19

M18X1.5

12

15

24

35

1BM-06-12

G3/8"X19

M12X1.5

13.5

12

22

33.5

1BM-06-14

G3/8"X19

M14X1.5

13.5

13

22

34.5

1BM-06-16

G3/8"X19

M16X1.5

13.5

14

22

35.5

1BM-06-18

G3/8"X19

M18X1.5

13.5

15

24

36

1BM-06-22

G3/8"X19

M22X1.5

13.5

17

27

40.5

1BM-08-16

G1/2"X14

M16X1.5

16

14

27

40

1BM-08-18

G1/2"X14

M18X1.5

16

15

27

41

1BM-08-20

G1/2"X14

M20X1.5

16

17

27

43

1BM-08-22

G1/2"X14

M22X1.5

16

17

27

43

1BM-08-26

G1/2"X14

M26X1.5

16

18

32

45

1BM-12-22

G3/4"X14

M22X1.5

18.5

17

32

46.5

1BM-12-26

G3/4"X14

M26X1.5

18.5

18

32

47.5

1BM-12-30

G3/4"X14

M30X1.5

18.5

20

36

49

1BM-16-33A

G1"X11

M33X2

20.5

20

41

54
