HOSE BORE

DIMENSIONS

PART NO.

DN

DASH

D

L

00TF0-02

4

2

9.5

14.3

00TF0-03

5

3

11.9

27.5

00TF0-04

6

4

14.2

30.7

00TF0-05

8

5

16

30.6

00TF0-06

10

6

19

32.1

00TF0-08

12

8

23.8

34.3

00TF0-10

16

10

27

37

00TF0-12

20

12

30.2

42.8

00TF0-14

22

14

33.4

42.7

00TF0-16

25

16

36.5

50.8
