THREAD

TUBE.O.D.

DIMENSIONS

PART NO.

E

F

D

A

L1

S1

S2

2MC-10-12WD

M10X1

M12X1.5

6

8

24.5

14

14

2MC-12-14WD

M12X1.5

M14X1.5

8

12

26.5

17

17

2MC-14-16WD

M14X1.5

M16X1.5

10

12

27.5

19

19

2MC-16-18WD

M16X1.5

M18X1.5

12

12

30.5

22

22

2MC-18-22WD

M18X1.5

M22X1.5

15

12

31.5

24

27

2MC-22-26WD

M22X1.5

M26X1.5

18

14

31.5

27

32

2MC-26-30WD

M26X1.5

M30X2

22

16

32.5

32

36

2MC-33-36WD

M33X2

M36X2

28

18

35

41

41

2MC-42-45WD

M42X2

M45X2

35

20

42.5

50

50

2MC-48-52WD

M48X2

M52X2

42

22

46.5

55

60
