THREAD

DIMENSIONS

PART NO.

E

F

A

B

L

S

1EH-12-10

M12X1.25

M10X1

11

9.5

28

14

1EH-14-12

M14X1.5

M12X1.5

11

11

28

17

1EH-16-14

M16X1.5

M14X1.5

11

11

28

19

1EH-18-16

M18X1.5

M16X1.5

11

11.5

31.5

22

1EH-22-18

M22X1.5

M18X1.5

12

12.5

34.5

24

1EH-27-22

M27X1.5

M22X1.5

13

15

38

30

1EH-30-27

M30X1.5

M27X2

14

18.5

43.5

32

1EH-36-33

M36X2

M33X2

16

18.5

47.5

41

1EH-39-33

M39X2

M33X2

18

18.5

49.5

41

1EH-42-42

M42X2

M42X2

20

19

54

50

1EH-45-42

M45X2

M42X2

21

19

54

50

1EH-52-48

M52X2

M48X2

22

21.5

58.5

55
