HOSE BORE

DIMENSIONS

PART NO.

FLANGE SIZE

DN

DASH

C

D

L

87313-12-12

3/4"

20

12

38.1

31.7

7

87313-16-12

1"

20

12

44.4

38

8.2

87313-16-16

1"

25

16

44.4

38

8.2

87313-20-16

1.1/4"

25

16

50.8

43.2

8.2

87313-20-20

1.1/4"

32

20

50.8

43.2

8.2

87313-24-20

1.1/2"

32

20

60.3

50.3

8.2

87313-24-24

1.1/2"

38

24

60.3

50.3

8.2

87313-32-24

2"

38

24

71.4

62.2

9.8

87313-32-32

2"

51

32

71.4

62.2

9.8
