HOSE BORE

DIMENSIONS

PART NO.

FLANGE SIZE

DN

DASH

F

B

L

87641-08-08

1/2"

12

08

31.7

23.9

7.9

87641-12-12

3/4"

20

12

41.3

31.7

8.9

87641-16-16

1"

25

16

47.6

38

9.6

87641-20-20

1.1/4"

32

20

54

43.6

10.4

87641-24-20

1.1/2"

32

20

63.5

50.8

12.7

87641-24-24

1.1/2"

38

24

63.5

50.8

12.7

87641-32-24

2"

38

24

79.4

66.5

12.7

87641-32-32

2"

51

32

79.4

66.5

12.7
