HOSE BORE

DIMENSIONS

PART NO.

FLANGE SIZE

DN

DASH

F

H

B

L

87341-08-08

1/2"

12

08

30

23.3

23.9

7

87341-12-12

3/4"

20

12

38

29.6

31.7

7

87341-16-16

1"

25

16

44

30.4

38

8.2

87341-20-16

1.1/4"

25

16

51

30.4

43.2

8.2

87341-20-20

1.1/4"

32

20

51

34.5

43.2

8.2

87341-24-20

1.1/2"

32

20

60

38

50.3

8.2

87341-24-24

1.1/2"

38

24

60

42

50.3

8.2

87341-32-32

2"

51

32

71

49.1

62.2

9.8
