E

HOSE BORE

DIMENSIONS

PART NO.

THREAD E

DN

DASH

TUBE O.D.

C

S

10411-12-04

M12X1.5

6

04

6

10.7

14

10411-12-04C

M12X1.25

6

04

6

10.7

14

10411-14-04

M14X1.5

6

04

8

13

17

10411-16-05

M16X1.5

8

05

10

13.5

17

10411-18-06

M18X1.5

10

06

12

13.5

19

10411-20-08

M20X1.5

12

08

14

13.5

22

10411-22-08

M22X1.5

12

08

15

13.5

24

10411-24-08

M24X1.5

12

08

18

13.5

27

10411-26-10

M26X1.5

16

10

18

14

27

10411-27-10

M27X1.5

16

10

18

14

30

10411-30-12

M30X2

20

12

22

18

32

10411-36-16

M36X2

25

16

28

18

38

10411-45-20

M45X2

32

20

35

19

46

10411-52-24

M52X2

38

24

42

19

55
