HOSE BORE

DIMENSIONS

PART NO.

FLANGE SIZE

DN

DASH

C

H

D

L

87643-12-12

3/4"

20

12

41.3

31.8

31.7

8.9

87643-16-12

1"

20

12

47.6

33.2

38

9.6

87643-16-16

1"

25

16

47.6

34

38

9.6

87643-20-16

1.1/4"

25

16

54

35.3

43.6

10.4

87643-20-20

1.1/4"

32

20

54

39.4

43.6

10.4

87643-24-20

1.1/2"

32

20

63.5

41.5

50.8

12.7

87643-24-24

1.1/2"

38

24

63.5

45.5

50.8

12.7

87643-32-24

2"

38

24

79.4

45.5

66.5

12.7

87643-32-32

2"

51

32

79.4

52.7

66.5

12.7
