E

HOSE BORE

DIMENSIONS

PART NO.

THREAD E

DN

DASH

A

C

H

S1

S2

29641-04-04

G1/4"X19

6

04

43.4

8

21.3

19

19

29641-06-06

G3/8"X19

10

06

48.9

9

24.6

22

22

29641-08-08

G1/2"X14

12

08

62.5

12

27.5

27

27

29641-12-12

G3/4"X14

20

12

81.3

13.5

33.9

32

32

29641-16-16

G1"X11

25

16

87.3

16

36

41

41

29641-20-20

G1.1/4"X11

32

20

107

18.5

46.5

50

50

29641-24-24

G1.1/2"X11

38

24

123

19

50.8

55

55

29641-32-32

G2"X11

51

32

143

23

60

70

70
